Electrical Requirement:
• 380V / 50Hz / 3 Phrase 5 Wires
1 Dia.of screw mm 52
2 Max theoretical injection capacity cm3 280
3 Total power for charging barrel kw 10.5
4 Plasticising capacity approx g/s 58
5 Clamping force of injection mold kn 600
6 Opening stoke of injection mold mm 120
7 Clamping force of blow mold kn 80
8 Opening stoke of blow mold mm 120
9 Dry cycle time s 3.2
10 Max swing radius mm 570
11 Liftion height of rotary table mm 60
12 Max plane size of mold(L*W) mm 680*400
13 Min mold thickness mm 280
14 Motor power kw 30
15 Mold heating power kw 6
16 Pressure of hydraulic system Mpa 14
17 Max working pressure of compressed air Mpa 1
18 Discharge rate of compressed air m3/min 0.8
19 Consumption of cooling water m3/h 6
20 Dimension of machine(L*W*H) mm 4000*1490*2400
21 Machine weight T 7
22 Range of formability product ml 3-500
23 Height of formability product mm ≤160
24 Dia.of formability product mm ≤80
Above machines are suitable for PP,PE,PS,ABS,PVC,BAREX,PC material,and one layer bottle producing
