Materials PE、PP…
Heads Set 1、2、3、4
Theoretic oupput Pcs/h 1400
Dimension (L×W×H) M
Max. Contanier L 2
Weight T 3
Heads
No. of Heating Zone ZONE 3
Heating power KW 4
Max. Die Dia. MM 90
Central Distance of Bi-die MM 130
Central Distance of tri-die MM 85
Central Distance of four-die MM 65
Camping system
Clamping force KN 60
opening stroke MM 138~368
Platen dimension(W×H) MM 300×320
Power
Oil pump drive power KW 7.5
Motor Power for screw KW 11
Fan power for screw KW 0.25
Blowing pressure MPA 0.6
Air consumption 0.4
Full load KW 28
plasticizing
Dia. Of screw MM 50
Screw L/D Ratio L/D 24:1
Shooting weight (HDPE) KG/H 30~50
Heating zone ZONE 3
Heating power KW 6.6
