Suitable Raw Material 　 PE/PP/PC
Max. Volume of Product L 2
Screw Diameter mm 55
Screw L/D Ratio L/D 25:1
Screw Speed rpm 20-60
Plasticising Capacity Kg/h 45
Number of Heating Zone 　 3
Extruder Heading Power KW 10
Die Heating Zone 　 2
Die Heating Power KW 4.2
Extruder Driving Power KW 11
Clamping Force KN 50
Air Pressure Mpa 0.6
Air Consumption m3/h 0.4
Machine Weight Kg 3000
Machine Dimension m 3.0*2.1*2.2
