Material PE.PP.PA.PVC……
Max container capacity 8L
Number of die set Single. Double. Four
capacity 250 Pc/hr
Machine dimension(L x W x H) 3.2x1.85x1.75m
Total weight 5ton
Clamping unit 50 KN
Platen force 150-450Mm
Platen opening stroke Mm 500x300
Max mould size(W x H) Mm 390x300
Mould thickness Mm 153-300
Max drive KW 11
Total power KW 25
Air pressure Mpa 0.6
Air consumption m3/min 0.8
Average energy consumption KW/hr 11
Screw diameter Mm Φ75
Screw L/D ration L/D 23:1
Plasticising capacity Kg/hr 75
Number of heating zone zone 5
Extruder driving power KW 11
Number of heating zone KW 3-5
Power of dieheating heating KW 4
Max die-pin diameter mm Φ150
Center distance of double die L 190
