Screw Diameter mm Φ75
Screw L/D ratio 24/1
Extruding capacity per hour L/H 80/1
Product capacity c.c. 300~5000
Switch on/off mold imitation mm 170~470
Min/Max diameter of product mm Φ30~160
Weight of product g 20~270
Frequency conversion motor HP 18.5
Pump driven motor HP 11
Number of heaters zone7
Heating capacity KW 7.5
Clamping force T 6
Fuel tank capacity Gallon 31
Net Weight T 5
Size mm 2550×3640×2500
